Quite Universal Circuit Simulator, Kartoniert / Broschiert

Klappentext

Please note that the content of this book primarily consists of articles available from Wikipedia or other free sources online. Quite Universal Circuit Simulator (Qucs) is a open source electronics circuit simulator software released under GPL. It gives you the possibility to set up a circuit with a graphical user interface and simulate the large-signal, small-signal and noise behaviour of the circuit. Pure digital simulations are also supported using VHDL and / or Verilog. Qucs supports a growing list of analog and digital components as well as SPICE sub-circuits. It is much simpler to use and handle compared to other circuit simulatorrs like gEDA..or PSPICE.
